HH Electronics TRM-1201 HH TENSOR Active Stage Monitor – 800W, 12″ LF Driver, 1″ Compression Driver
DUAL SWITCHABLE AUDIO MODES — A dedicated Monitor/FOH mode switch allows instant switching between stage monitoring a...
Read More
Couldn't load pickup availability
DUAL SWITCHABLE AUDIO MODES — A dedicated Monitor/FOH mode switch allows instant switching between stage monitoring and front-of-house applications, making the TRM-1201 a highly adaptable active monitor for any live setup.
HH-DESIGNED DRIVER PAIRING — Features a 12-inch HH LF driver and a 1-inch HH compression driver delivering full-range audio up to 130dB SPL across a wide 80° x 80° symmetrical coverage pattern.
HIGH-EFFICIENCY CLASS D AMPLIFICATION — Powered by a Class D amplifier rated at 350W RMS, 700W Continuous, and 1400W Peak, providing clean, reliable output with minimal heat generation during extended performances.
COMPREHENSIVE PROTECTION AND SIGNAL MONITORING — Dual band limiters safeguard the system against overload, while dedicated Power, Signal Present, and Clip indicators give real-time visual feedback of system status.
ROBUST AND PORTABLE CONSTRUCTION — Built with an acoustically optimised plywood cabinet, rear reinforced heavy gauge steel grille with acoustic foam, 35mm pole socket, and a switchable voltage supply for use across the UAE and internationally.
| Product Details | |
|---|---|
| Barcode | 5060109457582 |
| Model | TRM-1201 |
| Country of Origin | China |
| Color | Black |
| Dimensions | 51 × 34 cm |
| Item Weight | 21 |
| Series | Tensor Series |
| Series | Tensor Series |
| Tech Specs |
|---|
| Power Rating: 350W RMS, 700W Continuous, 1400W Peak |
| Frequency Response: 50Hz – 20kHz (-10dB) FOH Mode; 55Hz – 18kHz (-3dB) |
| Max SPL: 130 dB SPL |
| LF Driver: 12-Inch HH LF Driver |
| HF Driver: 1-Inch HH Compression Driver |
| Coverage: 80° Horizontal x 80° Vertical |
| Amplifier Type: Class D |
| Crossover Frequency: 2.8kHz |
| Input Connectors: Balanced Female XLR/6.3mm Jack Combi Socket |
| Output Connectors: Balanced Male XLR with Ground Lift Switch |
| Indicators: Power, Signal Present, Clip Indicator |
| Protection: Dual Band Limiters |
| Controls: Volume, Monitor/FOH Mode |
| Finish: Black |
| Grille: Rear Reinforced Heavy Gauge Steel Grille with Acoustic Foam |
| Others: 35mm Distance Pole Socket |
| AC Power: User Switchable 100–120V~ or 220–240V~ 50/60Hz |
| Power Consumption: 300W |
| Package Contents |
|---|
|
Driven by a 12-inch HH LF driver and a 1-inch HH compression driver, the TRM-1201 reproduces audio across a frequency range of 50Hz to 20kHz with a maximum SPL of 130dB. The symmetrical 80° x 80° dispersion pattern ensures consistent coverage whether positioned as a floor wedge or elevated on a pole. A high-efficiency Class D amplifier delivers 1400W Peak power, while dual band limiters and a full indicator set maintain system integrity throughout demanding performances.
The dedicated Monitor/FOH mode switch makes transitioning between stage and front-of-house roles effortless, eliminating the need for a separate speaker in smaller setups. The acoustically optimised plywood cabinet, heavy gauge rear steel grille, and switchable voltage compatibility make the TRM-1201 a durable, tour-ready active monitor suited to venues, outdoor events, and permanent installations across Dubai, Abu Dhabi, and the wider UAE.
