| Tech Specs |
| Keyboard : 88 Keys (A0–C8), Hammer Action with Aftertouch |
| Case : Aluminum Case with Wooden Side Panels |
| Operating System : Upgradable Operating System |
| Sound Generator : EDS-XP (Enhanced Definition Synthesis-Expanded) |
| Polyphony : 160 Voices, 160 Oscillators |
| Effects : Keyboard Tracks—3 Insert Effects, 3 Master Effects; Style/Song—10 Insert Effects, 3 Master Effects; Master EQ and Finalizer; Waves MaxxAudio® Suite |
| Mic Processor : Compressor, EQ, Gate, Four-Part Harmonizer, Doubler, Filter, Modulation, Delay, Reverb, AutoPitch |
| Guitar Processor : Guitar Rack with 4 Effect Slots, Stompbox and Amp Simulation |
| Factory Sounds : More than 2,200 |
| Factory Drum Kits : More than 130 |
| User Sounds : 768 |
| User Drum Kits : 384 |
| Digital Drawbars : 9 Footages, Percussion, Key On/Off, Leakage, Vibrato/Chorus, Rotary Speaker with Amp Simulator |
| Sampling : 4 GB User PCM Sample Memory, KORG/WAV/AIFF/SoundFont™ Support |
| Factory Keyboard Sets : More than 500 |
| Keyboard Sets : 4 Keyboard Sounds with Effects and Settings |
| Players : Patented XDS Crossfade Dual Player with X-Fader Balance Control |
| Factory Styles : More than 600 |
| Style Tracks : 8 |
| Style Elements : 3 Intros, 4 Variations, 4 Fills, 1 Break, 3 Endings |
| Chord Sequencer : More than 200 Factory Chord Sequences |
| Songs : MID, KAR, MP3 + Lyrics, MP3+G |
| Sequencer : 16-Track Sequencer with Song Edit |
| MP3 Player/Recorder : Dual MP3 Player and MP3 Recorder |
| SongBook : Programmable Music Database with Filtering, Sorting and User-Definable Set Lists |
| Pads : More than 400 Factory Pads, 4 Assignable Pads with Stop Buttons |
| Control Section : 9 Assignable Sliders, 9 Assignable Buttons, Strip Display |
| Matrix Section : 16 Matrix Pads, 4 Preset Buttons |
| General Controls : Master Volume, Octave Transpose, Master Transpose, Dial, Joystick, Ribbon, 3 Assignable Switches, Search, Shift, Split, Ensemble and More |
| Scale Controls : Quarter Tone and Arabic Scale |
| Control Inputs : Damper Pedal with Half-Pedaling Support, 2 Assignable Pedal/Footswitch Inputs |
| Audio Inputs : Mic, Guitar, Line 1, Line 2 |
| Audio Outputs : Main Left/Right, Separate Outs 1/2/3/4, Headphones |
| Video Output : HDMI |
| MIDI : IN, OUT, THRU, USB MIDI, 16 User-Definable MIDI Presets |
| USB : 1 × USB Type A Front, 2 × USB Type A Rear, 1 × USB Type B Rear |
| Storage : 1 GB Internal Drive, Micro SD Card Slot, USB Flash Drive Support |
| Display : 8” Wide Capacitive Color TouchView™ TFT, 800 × 480 Resolution |
| Power Consumption : 100–240 V, 50/60 Hz; Less Than 0.2 W Standby, 20 W Normal, 45 W with PaAS Installed |
